CB2 is an ultra-high performance scientific camera integrating Sony CMOS sensors specifically designed for research and applications requiring flexibility, speed and low noise. The CB2 series offers a spectral sensitivity from 200 to 1000 nm with resolutions ranging from 0.5 MP to 24.5 MP. Its internal hydraulic cooling enables the study of phenomena in the most light-starved conditions.
Designed specifically around the CMOS IMX530 sensor from Sony, which provides a small pixel pitch across a large area, the Andor CB2 24B camera is a breakthrough combining high sensitivity and high resolution over a large sample field-of-view.
Thanks to its 2×2 on-chip binning, Andor CB2 24B uniquely allows the native 2.74 µm pixels to be converted to a 5.78 µmwithout doubling of readout noise. For your experiments requiring long exposure times, Andor CB2 24B stands out from the competition thanks to its very low dark current. By suppressing the need for stitching/mosaicing and allowing high speed snapshot imaging, the camera enables groundbreaking high-speed large field of view live imaging of microscopy features and dynamics
Main Features
| Sensor size (W x H) | 5328 x 4608 (24.5 MP |
| Pixel pitch | 2.74 um (5.48 um with 2×2 on-chip binning) |
| Dynamic range | 80 dB (HDR) |
| Speed (full frame, 12-bits) CoaXPress SFP+ 10GB (Ethernet or Fiber) |
74 fps 32fps |
| Interface | CoaXPress 2.0 (CXP-12, 4 ports) SFP+ 10 GB interface (Ethernet or Fiber) |
| Readout noise | 1.30 e- RMS |
| Dark current | 0.0015 e-/p/s at -20°C 0.0044 e-/p/s at 0°C |
| Full well capacity (0 dB) | 9500 e- |
Mechanical Features
| Size | H77.5 x W93.0 x L177.5 mm |
| Weight | 1.1 kg |
| Max Power consumption | 60 W |
| Front filter thread | C-/TFL- Mount |
