ANDOR – OptistatDry TLEX
A Cryofree® optical cryostat for spectroscopy applications providing a temperature-controlled, sample-in-exchange-gas measurement environment, with sample access via a unique top-loading mechanism.
- Wide sample temperature range: < 4 K to 300 K
- Easy set-up and operation, no liquid cryogens are required
- Unique sample loading, reducing time between experiments
- Temperature range: < 4 K to 300 K
- Temperature stability: ± 0.1 K
- Vibration: typical RMS displacement of 10 microns at the sample position
- Room temperature to base temperature: < 6 hours
- Sample change time: < 45 minutes (sample can be changed with the cryostat cold)
- Cooling power: ~ 0.2 W at 5 K
- Sample space size: 20 mm diameter
- Optical access: f1
- Dimensions (HxWxD): 800-880 (adjustable) x 240 x 400 mm
- Total cryostat weight: 28 kg
