High Speed Linear THz camera is our brand new product, which features both, unprecedented imaging speed of 5000 frames per second and ease of integration into any industrial process. Its ultrafast linear sensor array is built to satisfy the needs in Non- Destructive Testing (NDT) and Quality Control (QC) for many industrial applications employing high speed conveyors belts.
✔ Image acquisition rate: 5 KHz (5000 fps)
✔ Scanning speed: up to 15m/sec (900m/min)
✔ Spectral range: 50 GHz – 0.7 THz
✔ Number of pixels (scalable): 256 x 1
✔ TeraFast® Viewer software
✔ Warranty period: 1.5 years
High Speed Linear THz camera is our brand new product, which features both, unprecedented imaging speed of 5000 frames per second and ease of integration into any industrial process. Its ultrafast linear sensor array is built to satisfy the needs in Non- Destructive Testing (NDT) and Quality Control (QC) for many industrial applications employing high speed conveyors belts. This product fits most conveyors with a belt speed up to 15 m/s.
Our Linear Terahertz Imaging System consists of two parts: a terahertz imaging camera and THz generator, both optimized & synchronized to each other. The generator is supplied with a specially configured horn antenna designed to cover the entire imaging area across conveyor belt. The horn spreads THz beam evenly and ensures that the whole THz radiation power is properly delivered from the generator into the camera. The camera pixel size determines image resolution of 1.5 mm, which is more than ample to support imaging in most industrial applications.
Layout for Linear Terahertz Imaging System installation on conveyor
TeraSense series of IMPATT diodes are silicon double drift diodes with a 0.6 um transit region, mounted on copper heat sink. The layers in double-drift diodes are: a heavily doped (p+)-region, a moderately doped pregion, a moderately doped n-region, and a heavily doped (n+)-region. The (p+)- and (n+)- regions allow ohmic electrical contacts to be made to the external circuit. The device relies on negative resistance to generate and sustain an oscillation.
Terasense is now offering its upgraded version of IMPATT diode. The upgraded IMPATT diode is outfitted with a protective isolator, which significantly improves output power stability. From now on you can order IMPATT diode with either rigidly fixed horn antenna or WR- flange of your choice. Typical output rfpower of IMPATT diode with optimized frequency @ 100 GHz can reach up to 80 mW.
Upgraded IMPATT Diode Specifications
IMPATT diode @ 100 GHz
(with case and current source)
Frequency: optimized at ~ 100 GHz
Protective isolator
TTL Modulation (1us rise/fall time)
High power (~80 mW output rfpower)
Conical horn antenna (rigidly fixed)
—- or —–
Ultrafast detectors by TeraSense consistently demonstrate response time of less than 150 ps. This was confirmed by direct observation of its impulse response function. The detector was excited by 200 nJ 1 ps laser pulse with a broad spectrum ranging from 0.1 to 3 THz, and its response was recorded by a high speed oscilloscope. The response function shows rise and fall times of 150 ps limited by the oscilloscope 4 GHz bandwidth.
The measured short response time makes it possible to use our detectors for straightforward investigation of fast transient processes in THz-science and telecommunication.
TeraSense® detectors are sensitive in a wide frequency range. However their frequency response is not continuous, but consists if multiple bands (peak structures). Positions of the peaks in responsivity curve can be tuned at manufacturing stage to suit specific client’s requirements.
Our ultrafast high-sensitive sub-THz detectors are meant for exploring fast-changing and transient sub-THz signals and impulses. Terasense detectors are actually expediting the advent of ultra-high-speed wireless telecommunication networks that is about to happen in the nearest future. Terasense ultrafast detectors are also an ultimate tool for characterization, calibration and tuning of impulse sub-THz sources.
The uSight-X is a compact Micro-Spectroscopy module that offers users the flexibility to connect, via optical fibre cable, different types of detectors ranging from compact spectrometer to high-end research grade spectrograph.The module is ideal for laboratories that requires the flexibility to utilize existing or varying combination of spectrometers or spectrographs for varying samples and can be configured to cover measurement such as Raman, Photoluminescence and Fluorescence.
Dual or even triple modules with different excitation wavelength can also be stacked and used with existing microscopy techniques such as DIC, Fluorescence, Dark-field, polarization, etc, imaging.
uSight is the state of the art micro-spectroscopy system that integrates UV-VIS-NIR Spectroscopy with the high precision of a research grade upright optical microscope. The uSight series developed by Technospex provides the complete set up for laboratories and industries that demands high performance, ease of use, and yet remaining cost effective for micro-spectroscopy applications.
The uSight-2000 Micro-Spectrophotometer is the new basic set up for advanced research or testing. It offers the versatility and sensitivity with down to 1.0 um measurement spot for accurate transmission, reflectance, absorbance, fluorescence, photoluminescence spectral measurement, with optional mapping function.
AtCor Medical Pty Ltd., developer and marketer of the SphygmoCor® system, is the market leader in noninvasive measurement of central arterial pressure waveform analysis and arterial stiffness assessment.
An Australian-headquartered company, AtCor Medical Limited’s corporate, manufacturing and R&D operations are located in Sydney. The American subsidiary, AtCor Medical Inc., is headquartered in Itasca, IL.
Central arterial pressure waveform analysis and pulse wave velocity from the industry leader.
SphygmoCor® technology is used clinically for central arterial pressure waveform analysis to better inform blood pressure management. The SphygmoCor system helps physicians individualize care for patients with hypertension, renal disease, COPD, diabetes and heart failure, among other diseases and conditions.
In clinical practice and clinical trials, SphygmoCor XCEL is the industry standard for noninvasive central arterial pressure waveform management. SphygmoCor XCEL provides measures of the central arterial pressure waveform and pulse wave velocity as well as an assessment of arterial stiffness via waveform analysis (e.g., augmentation index, augmented pressure and reflected wave magnitude).
SphygmoCor® XCEL PWA
SphygmoCor XCEL PWA (pulse wave analysis) uses a standard brachial cuff to measure brachial systolic and diastolic pressures, and capture a brachial waveform. The brachial waveform is then analyzed by SphygmoCor to provide a central aortic waveform. Central blood pressure measurements such as central aortic systolic blood pressure, central pulse pressure and an augmentation index are also reported
To conduct a carotid-femoral PWV measurement, a cuff is placed around the femoral artery of the patient to capture the femoral waveform, and a tonometer is used to capture the carotid waveform. The distance between the carotid and femoral arteries is measured, and the velocity automatically determined by dividing the distance by the pulse transit time.
The SphygmoCor cardiovascular management system (CVMS) is a tonometry-based device used to noninvasively obtain vital cardiovascular data that cannot be obtained with traditional brachial cuff blood pressure measurements. SphygmoCor CVMS allows clinicians and researchers to measure the pressures that the heart, brain and kidneys actually experience.1
SphygmoCor® CVMS
The SphygmoCor cardiovascular management system (CVMS) is a tonometry-based device used to noninvasively obtain vital cardiovascular data that cannot be obtained with traditional brachial cuff blood pressure measurements. SphygmoCor CVMS allows clinicians and researchers to measure the pressures that the heart, brain and kidneys actually experience.1
The SphygmoCor CVMS product line includes:
The SphygmoCor CP System
The SphygmoCor CPV System
The SphygmoCor CPVH System
The SphygmoCor® CP System
The SphygmoCor CP system includes pulse wave analysis (PWA) software only. During a PWA measurement, a 10-second snapshot of the radial arterial pressure wave is measured using a tonometer. The SphygmoCor software derives the ascending aortic pressure wave, substantially equivalent to the pressure wave measured by an invasive catheter. From the aortic pressure wave, a number of valuable cardiovascular measurements are determined, including central aortic systolic pressure, aortic augmentation index and central pulse pressure.
The SphygmoCor® CPV System
The SphygmoCor CPV system includes both pulse wave velocity (PWV) and PWA software. With the SphygmoCor CPV, PWV measurements can be taken between any two pulse points in the body; however, aortic PWV, measured with readings at the carotid and femoral arteries, has been shown to be the most predictive of cardiovascular risk.
The SphygmoCor® CPVH System
In addition to pulse wave velocity and pulse wave analysis software, the SphygmoCor CPVH system also provides heart rate variability (HRV) software. The SphygmoCor HRV software provides analysis of both time and frequency domains, and measures of sympathetic and parasympathetic activity. The system allows standard HRV measurements to be measured over 6 hours, as well as Valsalva and standing maneuver HRV measurements to be performed.
Nikon Stereo Microscopes SMZ445 and SMZ460 deliver the outstanding optical performance you expect from Nikon’s cutting-edge series of stereoscopic zoom microscopes. Porro prisms enable a lightweight, compact design. With 0.8x – 3.5x zoom magnification (SMZ445) and 0.7x – 3.0x zoom magnification (SMZ460), and diascopic/episcopic LED Stand, the SMZ445 and SMZ460 let you observe a wide range of specimens, from Petri dishes to plants, insects, small animals and minerals.
Nikon’s stereoscopic microscope with 7.5x zoom and 115 mm working distance — a superior model in this category.
Featuring a zoom magnification of 7.5X and a long working distance of 115mm, Nikon SMZ745 microscopes are well suited for both industrial and biomedical applications. The adoption of a new total reflection prism produces brighter images with higher contrast, and the anti-mold design allows the microscope to be used in environments where the temperature and humidity are high. The SMZ-745T trinocular model comes equipped with a microscope camera port and a built-in 0.55x c-mount adapter, permitting direct mounting of Nikon DS Series Digital Cameras.
Affordable Nikon Stereo Microscope model with 8:1 zoom ratio, streamlined operation and basic performance.
Versatile stereo microscope with improved operability and basic performance.
Nikon Stereo Microscope SMZ800N offers higher magnification than conventional models, enabling high-resolution observation of minute structures. In combination with the new objective series, its improved chromatic aberration correction provides bright and sharp images through the entire viewfield. The parallel optics design allows ergonomic accessories and observation attachments to be used in a wide range of applications.
